Flanged/Fabricated DIP
Flanged Joint ductile iron pipe spools are offered in sizes 3”-64” pipe diameter and lengths up to 20’ 0” long.
Grooved Fabricated DI Pipe
Grooved Joint ductile iron pipe spools are offered in sizes 3”-36” pipe diameter and lengths up to 20’ 0” long.
DI Wall Penetration Pipe
For DI piping passing through walls, DI Wall Pipe may be used. All DI Wall Pipe manufactured by C&B Piping are furnished with a wall collar welded continuously on both sides of the collar. This wall collar serves both as a waterstop and a thrust collar.
MJ HARNESS-LOK Fabricated DI Restraint
The MJ HARNESS-LOK joint is a restrained mechanical joint alternative to gripping style MJ restraints. It is offered in 3”-54” pipe sizes for ductile iron piping systems.
Fabricated Restrained Joint Closure Pieces
C&B Piping utilizes automated welding machines which use the submerged-arc welding process to apply OEM designed factory restrained joint weld beads onto ductile iron pipe.
Fabricated Victaulic Bolted Sleeve Coupling Closures
C&B Piping provides closure spool pipe connections to be used with restrained bolted sleeve couplings (Depend-O-Lok) manufactured by Victaulic.
Threaded Welded Outlets for Pipe & Fittings
C&B Piping manufactures Threaded Welded Outlets onto ductile iron pipe & fittings. These are also known as a Thread-O-Let. They are commonly used on fittings for locations where direct tapping the fitting is not recommended.
Flanged Weld On Bosses for Pipe & Fittings
C&B Piping provides Flanged Weld On Bosses outlets welded onto ductile iron pipe & fittings. The flanged outlets have threaded tapped bolt holes for direct installation of a spool for valve.
TYTON JOINT® Ductile Iron Pipe
C&B provides TYTON JOINT® ductile iron pipe for buried non restrained piping applications. We also apply various linings for water & wastewater which fit the application intended.
TR FLEX® Joint Ductile Iron Pipe
C&B can provide TR FLEX® Joint ductile iron pipe for buried restrained piping applications. We also apply various linings for water & wastewater which fit the application intended.
HP LOK® Joint Ductile Iron Pipe
C&B can provide HP LOK® Joint ductile iron pipe for buried restrained piping applications. HP LOK® is available in sizes 30”-64” diameter. We also apply various linings for water & wastewater which fit the application intended.
